Pipe Support & Clamping Systems

0 out of 5

Machine Support Technologies is proud to represent the quality pipeline support products of Tulsa Pipe Support Company (TPS). The Tulsa Pipe Supports and clamp systems are an excellent solution to your pipeline installation process allowing allowing simple removal for corrosion inspection and adjustability for full bearing load.

Manufactured using a tried and true epoxy load bearing resin system “Chockfast” which offers outstanding physical properties such as 15,250 psi compressive strengths and tensile strengths of 1,890 psi.

All pipe supports are shipped in pairs with ready to assemble Zinc-Plated threaded rod, nuts, and washers. Also available with Stainless Steel Hardware, pricing and availability upon request.

11_tulsapipesupports_2_500

Category: .

– Easy Removal for Pipe Inspection, Painting, or other Corrosion Control processes
– Fully Adjustable
– Dielectric Insulation (No need for Insulation Pads)
– Complies with D.O.T. – Office of Pipeline Safety Code of Federal Regulations
– Lower cost as compared to steel supports

Title 49 Part 192.479 thru 192.481 for Gas Transmission Pipelines
– Complies with D.O.T.
– Atmospheric Corrosion Control Part 195 for hazardous liquid pipelines
– Complies with D.O.T. / ASME Standard 192.161 Sections C & D
– Standard Sizes Fit 2” to 52” Diameter Pipe (Custom Sizes Available)
– Custom Designed Pier Mounting Plates and Installation

tulsa-pipe-support-diagram-watermark
